Agappe Diagnostics / Point of care
Q-3 Plus
Blood Coagulation Monitoring Device
Machines & equipment
Q-3 Plus is listed in Agappe’s point of care collection as a blood Coagulation Monitoring Device.
01 / A CLOSER LOOK
Features that
define the product.
- Reliable laboratory results in 30 -100 seconds for PT and 3 - 7 minutes for aPTT
- 10 μL of fingertip whole blood, fresh venous whole blood
- On board quality control
- External liquid QC (LQC) available
- Built-in temperature-controlled testing
- Built-in Barcode scanner
- No calibration or instrument re-programming required
- Interface Display Barcode scanner 3.5’’ 320×480 Colour LCD
- Barcode reading Software Language Multi-language menu English, Czech, German, French, Italian, Spanish, Portuguese, Dutch, Slovak, Romanian, Norwegian, Swedish, Danish, Polish, Greek
- Memory Capacity Patient Records Stores up to 2,000 patient records and 500 raw data
- Performance Measurable Range aPTT from 20 sec to 420 sec
- Dimensions 148mm x 70mm x 26mm (L× W × H) Weight 203 g
- Operating conditions Relative humidity: 10 % - 90 %
- Power supply 100V-240V AC Built-in 2,500mAH lithium polymer battery
02 / HOW IT WORKS
The technology.
Micro electrochemical system with micro fluidics. Q3 Plus electrometer detects the change of electric current across the clot and displays the result with internal matrix and calculations.
